D-Link® DNR-202L Network Video Recorder Item # 228557

 |
D-Link® DNR-202L Network Video Recorder
$ 99 .89 / each $99.89
Add a Protection Plan (optional)  Learn More
Includes Coverage For Accidental Drops & Spills
In Stock
Free delivery
Estimated delivery 20-30 business days

  • Lets you record video and audio from up to 4 video cameras.
  • 2 USB 2.0 ports connect to your own storage devices.

    Description

    You can use the mydlink camera video recorder to simultaneously stream, record and playback up to 4 D-Link Wi-Fi Cameras for affordable 24/7 home or small business security.

    • Lets you record video and audio from up to 4 video cameras.  For use with 1 or more mydlink-enabled Cloud Cameras, sold separately.
    • 2 USB 2.0 ports connect to your own storage devices.  Supports up to 2 external USB hard drives, sold separately, recording video and audio from up to 4 cameras.
    • Local storage gives you control over your recordings.  Can be used locally (where cameras are) or wherever an Internet connection exists.
    • Allows playback while recording.  While recording, you can play previously recorded video or view images in real time. Allows motion- or schedule-based recording of both video and audio. The free mydlink mobile app and portal allow remote viewing.
    • Sets up quickly and easily.  Features auto camera discovery and intuitive user interface.
    Back To Top

    Product Details

    Item # 228557
    OfficeMax # 24871453
    Manufacturer # DNR-202L
    Ethernet Technology Fast Ethernet
    HDMI Yes
    height 0.8 in
    Certifications & Standards CE; CE LVD; FCC; C-Tick
    Features Audio/Video Recorder
    video formats H.264; Motion JPEG; MPEG-4; JPEG; AVI
    Connectivity Technology Wired
    Total Number of Channels 4
    width 4.6 in
    Product Line mydlink
    depth 2.8 in
    Product Name mydlink Camera Video Recorder
    manufacturer D-Link Systems, Inc.
    Frame Rate 30 Frames Per Second
    Application/Usage Indoor
    weight 3.20 oz
    brand name D-Link
    USB Yes
    Power Consumption 8.50 W
    Ethernet Yes
    Input Voltage 5 V DC
    maximum resolution 1280 x 720
    color black/silver
    warranty length 1-year limited
    model name DNR-202L
    Show More ▾
    Back To Top

      Customer Reviews

      Rated 2.2 out of 5�by 6 reviewers.
      Rated 1 out of 5�by so so difficult time getting it to work correctly July 6, 2015
      Rated 1 out of 5�by Garbage Unreliable garbage, DO NOT BUY! BEWARE! May 17, 2015
      Rated 2 out of 5�by Only works with few low end DLink cameras I bought this with a 850L and then a 5092L. It only recognizes and works with our old 942L. Dlink needs to list the cameras this will work with OR make it compatible with all the cameras they make.. 2/5, would be 5/5 if it worked with other DLink cameras. April 5, 2015
      Rated 5 out of 5�by Great solution Does the job very well and it's easy to install / use. Real time recording is what I was looking for. I have 3 interior cameras and one exterior camera under management of the DNR-202L so I can see who's coming home and exactly when while I am away. . The fact that it is a standalone unit (not running on a pc) is a major plus since you can hide it anywhere. If someone break in, they might run with the pc but they will never see my DNR unit. March 14, 2015
      • 2016-04-01 T12:30:46.491-05:00
      • bvseo_lps, prod_bvrr, vn_prr_5.6
      • cp-1, bvpage1
      • co_hasreviews, tv_6, tr_6
      • loc_en_US, sid_228557, prod, sort_default
      2 next>>
      Back To Top

      From the Manufacturer|Powered by Webcollage

      Thank You Is the information in this section helpful? Yes / No

      Product Overview

      • D.I.Y. security made easy.

        Use the mydlink Camera Video Recorder to simultaneously stream, record and playback up to 4 D-Link Wi-Fi Cameras* for affordable 24/7 home or small business security.

      • Trigger Based Recording

        Ability to record whenever sound or motion is detected

      • Customized Storage

        2 USB ports to connect your own hard drives of up to 4TB each

      • Easy Setup

        Out of the box and into your home in minutes

      • No Monthly Fees

        Affordable home security that doesn't nickel and dime

      • Easy setup.

        Set up in just a few minutes with effortless do-it-yourself installation.

      • Step 1: Connect up to 2 Hard Drives

        Pick a size, pick a band - the mydlink Camera Video Recorder works with any external USB hard drive.

      • Step 2: Connect to Your Network

        Connect to the same network your cameras are on via ethernet.

      • Step 3: Get Instant Security

        Up to 4 D-Link W-Fi Cameras will be automatically detected and set up for recording.

      • A little space. A lot of recording.

        How much storage do you need? Depends on what you're watching. Use this chart to create the solution that's right for you.

      • Home security in the palm of your hand.

        Real-time monitoring, scheduling and playback from anywhere with the free mydlink View app.

      • Simple search and playback.

        Search for the video you want by choosing the camera and selecting the date/time. It's that easy.

      • Get your own complete security solution started today.

      • *The DNR-202L currently supports all D-Link Wi-Fi Cameras except the DCS-934L, DCS-935L, DCS-5009L, DCS-5010L and DCS-5029L. Support for the DCS-935L will be available early Q3 of 2015.
      See More:

      Product Tour

      {"tourViews":[{"viewImage":{"assetWrapper":"tour","runtimeSrc":{"height":936,"width":1664,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/8c27fea2-0656-49d6-a96a-66443d71a369.png.web.v1.jpg"},"isAdaCompliant":false,"src":{"height":936,"width":1664,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/8c27fea2-0656-49d6-a96a-66443d71a369.png"},"sources":[{"height":540,"width":960,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/8c27fea2-0656-49d6-a96a-66443d71a369.png.w960.jpg","profile":"W960"},{"height":270,"width":480,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/8c27fea2-0656-49d6-a96a-66443d71a369.png.w480.jpg","profile":"W480"},{"height":135,"width":240,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/8c27fea2-0656-49d6-a96a-66443d71a369.png.w240.jpg","profile":"W240"}]},"hotspots":[{"hotspotX":0.36428571428571427,"captionFromAttr":"Power & Network LED","direction":"left","description":"Blue indicates that your device is connected to the network and ready to go.","hotspotY":0.2974683544303797}]},{"viewImage":{"assetWrapper":"tour","runtimeSrc":{"height":936,"width":1664,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/11b93320-bd08-409e-8ccd-0a6b93efd7f9.png.web.v1.jpg"},"isAdaCompliant":false,"src":{"height":936,"width":1664,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/11b93320-bd08-409e-8ccd-0a6b93efd7f9.png"},"sources":[{"height":540,"width":960,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/11b93320-bd08-409e-8ccd-0a6b93efd7f9.png.w960.jpg","profile":"W960"},{"height":270,"width":480,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/11b93320-bd08-409e-8ccd-0a6b93efd7f9.png.w480.jpg","profile":"W480"},{"height":135,"width":240,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/11b93320-bd08-409e-8ccd-0a6b93efd7f9.png.w240.jpg","profile":"W240"}]},"hotspots":[{"hotspotX":0.364,"captionFromAttr":"Power Connector","direction":"left","description":"<p>Power adapter connection, 5V/3A<\/p>","hotspotY":0.38388625592417064,"media":{"assetWrapper":"tour","runtimeSrc":{"height":225,"width":400,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/c74c98db-55dc-425b-a485-86edd393460e.png.web.v1.400.jpg"},"isAdaCompliant":false,"src":{"height":225,"width":400,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/c74c98db-55dc-425b-a485-86edd393460e.png"},"type":"IMAGE","sources":[{"height":540,"width":960,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/c74c98db-55dc-425b-a485-86edd393460e.png.w960.jpg","profile":"W960"},{"height":270,"width":480,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/c74c98db-55dc-425b-a485-86edd393460e.png.w480.jpg","profile":"W480"},{"height":135,"width":240,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/c74c98db-55dc-425b-a485-86edd393460e.png.w240.jpg","profile":"W240"}]}},{"hotspotX":0.4746666666666667,"captionFromAttr":"Ethernet Port","direction":"left","description":"RJ-45 connection to a local network","hotspotY":0.5355450236966824},{"hotspotX":0.6093333333333333,"captionFromAttr":"USB Port 1","direction":"left","description":"USB port for external HDD 1","hotspotY":0.41232227488151657}]},{"viewImage":{"assetWrapper":"tour","runtimeSrc":{"height":936,"width":1665,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/6c51347a-3bbd-40ce-92f1-e89f924fba77.png.web.v1.jpg"},"isAdaCompliant":false,"src":{"height":936,"width":1665,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/6c51347a-3bbd-40ce-92f1-e89f924fba77.png"},"sources":[{"height":539,"width":960,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/6c51347a-3bbd-40ce-92f1-e89f924fba77.png.w960.jpg","profile":"W960"},{"height":269,"width":480,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/6c51347a-3bbd-40ce-92f1-e89f924fba77.png.w480.jpg","profile":"W480"},{"height":134,"width":240,"src":"/_cp/products/1379711551477/tab-c2b26a56-4505-45dc-9ce1-815222a2bfa5/6c51347a-3bbd-40ce-92f1-e89f924fba77.png.w240.jpg","profile":"W240"}]},"hotspots":[{"hotspotX":0.3293333333333333,"captionFromAttr":"Release button for HDD 1","direction":"left","hotspotY":0.4194312796208531},{"hotspotX":0.4653333333333333,"captionFromAttr":"USB Port 2","direction":"left","description":"USB port for external HDD 2","hotspotY":0.5165876777251185},{"hotspotX":0.5493333333333333,"captionFromAttr":"HD2 Button","direction":"left","description":"Release button for the HDD2 port","hotspotY":0.42890995260663506},{"hotspotX":0.6346666666666667,"captionFromAttr":"Auto Scan Button","direction":"left","description":"Used to scan for and add cameras on the local network","hotspotY":0.523696682464455},{"hotspotX":0.6813333333333333,"captionFromAttr":"Reset Button","direction":"left","description":"Used to reset the device back to factory default settings","hotspotY":0.43838862559241704}]}],"ipiCompatible":false}
      1. Power & Network LED
      2. Power Connector
      3. Ethernet Port
      4. USB Port 1
      5. Release button for HDD 1
      6. USB Port 2
      7. HD2 Button
      8. Auto Scan Button
      9. Reset Button
      Image/Features

      Power & Network LED

      Blue indicates that your device is connected to the network and ready to go.

      Power Connector

      Power adapter connection, 5V/3A

      Ethernet Port

      RJ-45 connection to a local network

      USB Port 1

      USB port for external HDD 1

      Release button for HDD 1

      USB Port 2

      USB port for external HDD 2

      HD2 Button

      Release button for the HDD2 port

      Auto Scan Button

      Used to scan for and add cameras on the local network

      Reset Button

      Used to reset the device back to factory default settings
      Product Tour
      Click to Start

      Specifications

      Video Format

      • H.264/MPEG-4/MJPEG for live streaming

      • JPEG for still images

      Audio Support

      • G.711

      • G.726

      Reset Button

      • Reset to factory default

      Auto Scan Key

      • IP Camera Finder (press for 3 seconds)

      External Device Interfaces
      		• 10/100 BASE-TX Fast Ethernet port

      • 2 x USB 2.0 ports for external HDD storage

      Video Management
      Live View/Playback Interface

      • HTTP Web Browser/mydlink.com Portal/mydlink View - NVR app

      Live View Display Modes

      • 1 and 4 channels display

      Recording Modes



      • Schedule, Manual, Event (Sound or Motion)

      • Continuous

       Recording Performance

      • H.264/MPEG4 720P @ 30 FPS : 32 Mbps

      Video Setting• Resolution/Quality/Frame Rate/Compression Format/Audio On and Off
      Playback Control

      • Play, Stop, Pause, Forward, Backward, Next, Previous

      Video Export Formats

      • Video: AVI

      Network

      Physical Interface

      • RJ45 10/100 LAN Ethernet (auto MDI/MDIX)

      Network Protocols

      • IPV4, ARP, TCP, UDP, ICMP

      • UPnP

      • DHCP Client

      • DNS Client

      • HTTP Server

      • HTTPS

      • SMTP

      • RTP

      • RTCP

      • RTSP

      • NTP

      Security

      User Management

      • Administrator password authentication

      Automatic Logoff

      • Idle user timeout on configuration pages

      System

      System Requirements

      • Microsoft Windows®: 8/7, Vista, or XP SP2

      • Mac OS X (10.5 or higher)

      Browser Requirements

      • Internet Explorer 8 or higher

      • Firefox, Chrome, Safari 5 or higher

      Mobile Support

      • Android 4.01 and above

      • iOS 5.1.1 and above

      Remote Management

      • Remote live view and playback via web browser

      • Configuration interface accessible via web browser

      System Log

      • Status of active users

      • Login history

      Certifications

      • CE

      • C-Tick

      • FCC

      • CE LVD

      Physical
      Weight

      • 0.2 lbs (90g)

      External Power Adapter

      • Input: 5 V DC, 3 A

      • Consumption: 8.5 watts ± 5 % (include 2 x 2.5 HDD)

      Temperature

      • Operating: 32°F to 104°F (0° to 40°C)



      • Storage: -4°F to 158 °F (-20° to 70 °C )

      Humidity

      • Operating: 10% to 90% non-condensing

      • Storage: 5% to 95% non-condensing

      Dimensions

      • 117.5 x 70 x 20.35mm
